ED2311R-FRAME Height Adjustable Sit-Stand Desk Frame (smart control panel)

Height Adjustable Sit-Stand Desk Frame (smart control panel)

  • Height Adjustable Sit-Stand Desk Frame
FEATURES
  1. Metal single leg with 3 columns height adjustable.
  2. Smart control Panel, 3 sets of memory digital preset, digits LED display
  3. Power: 100VAC - 230VAC,50/60Hz
  4. Distributed weight capacity: 80 kg
  5. Range of adjustment of height: 610-1260mm



Introduction

Enhance User Comfort
Height-adjustable tables minimize operator fatigue and discomfort by allowing users the freedom to sit or stand throughout the day.


Ergonomics to Increase Productivity
Making ergonomic improvements will also decrease employee absenteeism and turnover while reducing the risk for musculoskeletal disorders (MSDs) and eliminating or at least decreasing their incidences in the workplace.


Create Flexible Workspaces
Freestanding, height-adjustable tables adapt to the changing office environment. Universal Tables work in conjunction with systems furniture or plan independently to create flexible work areas.

Smart Control Panel
♦ 3 sets of memory digital preset
♦ Digits LED display
High Grade Steel Dual Leg With 3 Segments Column Height Adjustable
♦ Dual sync. motors
♦ Adjustment Travel:650mm
♦ Distributed Weight Capacity80Kg
Specification
Range of Adjustment of Height 610mm – 1260mm
Adjustment Travel 650mm
Distributed Weight Capacity 80 kg (220 lbs)
Controller Smart Control Panel; Up and Down; 3 sets of memory digital preset;Digits LED Display
 Motor Dual sync. Motors
Noise Decibel Rating < 50dBA
Adjustability Speed 35mm /Sec MAX
Duty Cycle 10%,Max (2 min.on/18 min.off)
Desk Top Surface Finish Durable commercial grade work surfaces with melamine finish that resists scratches, stains and burns
Color : Wood - Desk Top is optional item
Desk Top Size 1200mm x 800mm (WxD) - (desk top is optional item), customized size is acceptable
1580mm x 800mm (WxD)
Leg High grade steel Dual leg with 3 segments column height adjustable
Color : White
Foot Base Metal Material, with Rubber pads
Cross Bar(Optional) Metal Material (Optional)
Power 100VAC - 230VAC,50Hz/60Hz
Environment 5 to 40°C, 20% to 90% RH
-10 to 60°C, 5% to 95% RH
Color of Desk Frame
